Каталог запасных частей к технике: SEM655D (2015). Gear box assembly
1
2
3
3
5
5
6
7
9
10
12
12
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| B040811265 | B***5 | Bolt | |
| B040811270 | B***0 | Bolt | |
| B040910812 | B***2 | Bolt | |
| B040911435 | B***5 | Bolt | |
| B041111630 | B***0 | Bolt | |
| B050331412 | B***2 | Nut | |
| B060111404 | B***4 | Washer | |
| B060111604 | B***4 | Washer | |
| B060410802 | B***2 | Washer | |
| B060411002 | B***2 | Washer | |
| B060411203 | B***3 | Washer | |
| B070150001 | B***1 | Snap ring | |
| B070158003 | B***3 | Snap ring | |
| B080311230 | B***0 | Shaft pin | |
| B120910808 | B***8 | Bearing si8e | |
| B160120170 | B***0 | O-ring | |
| B160120190 | B***0 | O-ring | |
| W080200000 | W***0 | Parking brake air cavity | |
| Z3A01801500 | Z***0 | Adaptor | |
| Z3B553002 | Z***2 | Change oil pressure gauge into tubing joint | |
| Z510210500 | Z***0 | Spacer | |
| Z510211030 | Z***0 | Support column | |
| Z5500700300 | Z***0 | Speed bracket | |
| 1 | B***0 | Screw | |
| 2 | B***0 | Bolt | |
| 3 | B***0 | Bolt | |
| 4 | B***6 | Bolt | |
| 5 | B***5 | Bolt | |
| 5 | Z***0 | Nut | |
| 6 | B***5 | Bolt | |
| 7 | B***0 | Bolt | |
| 8 | B***0 | Bolt | |
| 9 | B***4 | Nut | |
| 10 | B***2 | Lock washer | |
| 11 | B***3 | Lock washer | |
| 12 | B***3 | Lock washer | |
| 13 | B***5 | Washer | |
| 15 | B***1 | Snap ring | |
| 16 | B***3 | Snap ring | |
| 17 | B***3 | Snap ring | |
| 18 | B***2 | Snap ring | |
| 19 | B***1 | Snap ring | |
| 20 | B***2 | Snap ring | |
| 21 | B***0 | Pin | |
| 22 | B***7 | Cotter pin | |
| 23 | B***0 | Pin | |
| 24 | B***5 | Spilt | |
| 26 | B***0 | Stud | |
| 27 | B***4 | Thread plug | |
| 28 | B***2 | Plug | |
| 29 | B***8 | Thread plug | |
| 30 | B***3 | Bearing | |
| 31 | B***9 | Bearing | |
| 32 | B***1 | Bearing | |
| 33 | B***1 | Bearing | |
| 35 | B***0 | Lock ring | |
| 36 | B***3 | Bearing | |
| 37 | B***0 | O-ring | |
| 39 | B***5 | O-ring | |
| 41 | B***5 | O-ring | |
| 42 | B***0 | O-ring | |
| 43 | В***1 | Oil seal | |
| 44 | B***3 | Skeleton type oil seal | |
| 45 | J***0 | Breather sfh-323s combined parts | |
| 47 | Z***0 | Gear | |
| 48 | Z***0 | Front output connecting flange | |
| 49 | W***0 | Oil indicator | |
| 51 | Z***2 | Box | |
| 52 | Z***0 | Clutch shaft | |
| 53 | Z***0 | Cover | |
| 54 | Z***0 | Input connecting flange | |
| 55 | Z***0 | Input shaft | |
| 56 | Z***0 | Clamping plate | |
| 57 | Z***0 | O-ring | |
| 58 | Z***0 | Input gear | |
| 59 | Z***0 | Gear | |
| 61 | Z***0 | Gear | |
| 62 | Z***0 | Output shaft | |
| 63 | Z***0 | Clamping plates | |
| 63 | Z***0 | Clamping plates | |
| 64 | Z***0 | O-ring | |
| 65 | Z***0 | Apron | |
| 66 | Z***0 | Joint sleeve | |
| 67 | Z***0 | Spring | |
| 68 | Z***0 | Bearing seat | |
| 69 | B***0 | Steel ball | |
| 70 | Z***0 | Sleeve | |
| 71 | Z***3 | Box | |
| 72 | Z***2 | Oil filler cap | |
| 73 | Z***0 | Seal ring | |
| 74 | Z***0 | Gasket | |
| 74 | Z***0 | Gasket | |
| 75 | Z***0 | Oil sealing board | |
| 76 | Z***0 | Sleeve | |
| 77 | Z***2 | Filler cap | |
| 78 | Z***0 | Input shaft cover | |
| 79 | Z***2 | Filler cap | |
| 80 | Z***0 | Seal ring | |
| 81 | Z***0 | Yoke | |
| 82 | Z***0 | Puling rod | |
| 83 | Z***0 | Screw | |
| 84 | Z***0 | Thread plug | |
| 85 | Z***0 | Spacer | |
| 86 | Z***0 | Small flange | |
| 87 | Z***0 | Clamping plate | |
| 88 | Z***0 | Nut | |
| 88 | Z***0 | Nut | |
| 88 | Z***0 | Nut | |
| 89 | Z***1 | H/L speed gear shaft sleeve | |
| 90 | Z***0 | Transmission nameplate | |
| 91 | N***0 | Clutch | |
| 92 | N***0 | Clutch | |
| 93 | N***0 | Clutch component | |
| 94 | Z***0 | Accumulator | |
| 95 | Z***0 | Left flange of oil filter | |
| 95 | Z***0 | Right flange of filter | |
| 96 | W***0 | Transmission control valve | |
| 97 | Z***0 | Oil retainer | |
| 98 | Z***0 | Transition plate | |
| 99 | Z***0 | Sleeve of inlet oil cover | |
| 100 | Z***7 | Breather joint | |
| 101 | Z***8 | Oil-through board | |
| 102 | Z***0 | Rear output connecting flange | |
| 103 | Z***0 | Thread plug | |
| 104 | Z***0 | Filter screen asy | |
| 105 | B***0 | O-ring | |
| 106 | B***0 | Pin | |
| 108 | B***2 | pin | |
| 109 | B***2 | Pin | |
| 110 | Z***0 | Set plate | |
| 115 | W***3 | Switch of reverse lamp pressure | |
| 116 | Z***2 | Return oil adapter | |
| 117 | Z***0 | Left bracket gear box | |
| 119 | Z***0 | Bracket | |
| 121 | Z***0 | Return oil adapter of converter | |
| 125 | Z***0 | Connecting plate | |
| 126 | B***0 | Nut | |
| 127 | B***7 | Retainer pin | |
| 129 | Z***0 | Bend arm | |
| 131 | B***6 | Pin | |
| 132 | Z***0 | Shaft pin | |
| 133 | Z***0 | Outlet or return oil part of gear box | |
| 135 | Z***0 | Fitting | |
| 136 | Z***0 | Right bracket gear box | |
| 138 | Z***0 | Pin | |
| 140 | Z***1 | Cool return oil adapter of gear box | |
| 141 | W***A | Sensing plug for temperature | |
| 142 | Z***0 | Adapter |
