Каталог запасных частей к технике: Geely FC (2008). LEFT SIDE WALL ASSY.
45
54
53
52
51
50
50
49
48
47
46
55
44
43
42
41
40
39
38
37
64
72
71
70
70
69
69
68
68
67
67
66
66
65
36
63
62
61
60
60
59
58
57
57
56
56
9
17
16
15
14
13
12
11
10
18
18
8
7
6
5
4
3
2
1
27
35
34
33
32
31
30
29
28
26
25
24
23
23
23
22
21
20
20
19
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1062000469 | 1***9 | LEFT SIDE WALL ASSY. | |
| 1 | L***Y | LEFT A-PILLAR INNER PLATE LOWER PART ASSY. | |
| 2 | L***Y | LEFT A-PILLAR INNER PLATE UPPER PART ASSY. | |
| 3 | L***E | LEFT A-PILLAR INNER PLATE CONNECTING PLATE | |
| 4 | L***Y | LEFT A-PILLAR LOWER GEMEL FIXING PLATE ASSY. | |
| 5 | F***Y | FL CHECK ROD FRAME ASSY. | |
| 6 | L***Y | LEFT A-PILLAR UPPER REINFORCEMENT ASSY. | |
| 7 | L***T | LEFT SIDE WALL LOWER REINFORCEMENT | |
| 8 | L***T | LEFT SIDE WALL LOWER FRAME CHECK BRACKET | |
| 9 | L***Y | LEFT SIDE WALL LOWER FRAME INNER LINER ASSY. | |
| 10 | L***T | LEFT SIDE WALL LOWER FRAME INNER LINER FRONT BRACKET | |
| 11 | L***T | LEFT SIDE WALL LOWER FRAME INNER REAR BRACKET | |
| 12 | L***R | LEFT SIDE WALL LOWER FRAME INNER LINER | |
| 13 | 1***3 | LEFT TAILLIGHT FIXING PLATE | |
| 14 | T***T | TAILLIGHT UPPER PLATE BRACKET | |
| 15 | T***T | TAILLIGHT SMALL BRACKET | |
| 16 | L***E | LEFT TAILLIGHT UPPER PLATE | |
| 17 | 1***1 | LEFT SIDE WALL OUTER PANEL | |
| 18 | D***Y | DOOR LOCK HOOK FIXING PLATE ASSY. | |
| 19 | L***T | LR DOOR LOCK HOOK REINFORCEMENT | |
| 20 | L***T | LEFT SIDE WALL UPPER FRAME REINFORCEMENT | |
| 21 | L***Y | LEFT SIDE WALL UPPER SIDE PLATE SUB-ASSY. | |
| 22 | L***E | LEFT 1# CROSS MEMBER CONNECTING PLATE | |
| 23 | L***Y | LEFT CENTER PILLAR INNER PLATE ASSY. | |
| 24 | L***Y | LEFT CENTER PILLAR OUTER PLATE REINFORCEMENT SUB-ASSY. | |
| 25 | L***T | LEFT CENTER PILLAR INNER PLATE REINFORCEMENT | |
| 26 | L***E | LF SAFETY BELT LOWER ADJUSTABLE PLATE | |
| 27 | L***Y | LF SAFETY BELT LOWER FIXING PLATE ASSY. | |
| 28 | L***Y | LR DOOR CHECK ROD FRAME ASSY. | |
| 29 | L***E | LEFT TRUNK BOARD SIDE PLATE | |
| 30 | L***Y | LEFT TRUNK BOARD UPPER PLATE SUB-ASSY. | |
| 31 | L***Y | LR PILLAR INNER PLATE ASSY. | |
| 32 | L***R | LR PILLAR QUARTER | |
| 33 | L***D | LEFT TRUNK BOARD | |
| 34 | L***E | LR CROSS MEMBER 3-WAYS CONNECTING PLATE | |
| 35 | L***Y | LR WHEEL INNER FRONT CONNECTING PLATE SUB-ASSY. | |
| 36 | F***Y | FUEL FILLER PIPE FIXING PLATE ASSY. | |
| 37 | L***E | LEFT TRUNK BOARD CONNECTING PLATE | |
| 38 | L***Y | LEFT CENTER PILLAR LOWER HINGE SEAT ASSY. | |
| 39 | R***Y | REAR SEAT SAFETY BELT FIXING PLATE ASSY. | |
| 40 | L***Y | LR SEAT FIXING BRACKET ASSY. | |
| 41 | R***D | REAR SEAT SIDE SUPPORT BOARD | |
| 42 | L***T | LR WHEEL BRAKE PIPE BRACKET | |
| 43 | L***Y | LR SEAT SIDE SUPPORT BOARD ASSY. | |
| 44 | H***T | HINGE SEAT REINFORCEMENT | |
| 45 | L***D | LEFT HINGE SEAT FIXING BOARD | |
| 46 | L***Y | LEFT HINGE SEAT FIXING BOARD REINFORCEMENT ASSY. | |
| 47 | L***Y | LR WHEEL OUTER COVER SUB-ASSY. | |
| 48 | L***R | LR WHEEL INNER COVER | |
| 49 | L***E | LR WHEEL INNER QUARTER CONNECTING PLATE | |
| 50 | L***Y | LEFT SIDE WALL LOWER FRAME REINFORCEMENT ASSY. | |
| 51 | 1***3 | LEFT TAILLIGHT FIXING PLATE | |
| 52 | G***T | GASOLINE TANK CAP CONTROL CABLE SEAT | |
| 53 | L***Y | LEFT CENTER PILLAR OUTER REINFORCEMENT ASSY. | |
| 54 | L***Y | LEFT CENTER PILLAR INNER REINFORCEMENT 1# SUB-ASSY. | |
| 55 | L***Y | LEFT CENTER PILLAR INNER REINFORCEMENT 2# SUB-ASSY. | |
| 56 | L***Y | LEFT CENTER PILLAR INNER REINFORCEMENT ASSY. | |
| 57 | L***Y | LEFT A-PILLAR INNER REINFORCEMENT PANEL ASSY. | |
| 58 | L***Y | LEFT SIDE WALL INNER REINFORCEMENT ASSY. | |
| 59 | L***Y | LR DOOR LOCK HOOK FIXING PLATE ASSY. | |
| 60 | L***Y | LEFT SIDE WALL OUTER PANEL ASSY. | |
| 61 | L***E | LR WHEEL INNER FRONT CONNECTING PLATE | |
| 62 | L***Y | LR WHEEL INNER COVER ASSY. | |
| 63 | L***Y | LEFT TRUNK BOARD ASSY. | |
| 64 | L***Y | LR WHEEL HOUSING ASSY. | |
| 65 | L***) | LEFT TRUNK BOARD SUB-ASSY. (2) | |
| 66 | L***Y | LEFT TRUNK MAINBOARD UPPER PANEL ASSY. | |
| 67 | L***) | LEFT TRUNK BOARD SUB-ASSY. (1) | |
| 68 | L***Y | LR WHEEL COVER ASSY. | |
| 69 | L***Y | LEFT SIDE WALL UPPER SIDE PLATE ASSY. | |
| 70 | L***Y | LEFT A-PILLAR INNER PLATE ASSY. | |
| 71 | L***Y | LEFT A-PILLAR INNER PLATE REINFORCEMENT ASSY. | |
| 72 | 1***9 | LEFT SIDE WALL ASSY. |
